10004390 - TDC - OEM Replacement Filter

  • $100.53
NAME YOUR DAMN PRICE - On orders of 6 filters or more. Try for free.

10004390 Filter Media Upgrades

  • Standard: 80/20 Cellulose/Polyester Blend - Max Temp: 180F. (MERV 11)
  • Upgrade: 100% Nanofiber FR - Max Temp: 170F. (MERV 15)
  • Upgrade: 100% Spun Bond Polyester: - Max Temp: 275F.
  • (See full filter media specs here.)

10004390 Details

OEM Make: TDC
Part Number: 10004390
Dimensions: 12.75 X 26.00 X 8.375
Outside Diameter: 12.75
Length: 26
Inside Diameter: 8.375
Top: open
Bottom: closed
Shape: round
Approx. Square Footage of Filter Media: 222.64
Notes:Bolt Hole OC W/BOLTHOLE

TDC dust collector filter by DAMN Filters.

Build details: Standard construction of cross reference 10004390 cartridge filter includes; heavy gauge steel structural elements, one-piece closed cell neoprene gasket, polyurethane potting compound, and flame resistant 80/20 Cellulose/Polyester blend filter media. (Nanofiber or Spunbond upgrades available.)

Part number history: Our internal configuration file for this TDC filter was updated last in September 2013. Our interchange control ID is, Top open DF-160410611-01 and is the proper dimension of a TDC replacement filter for part number 10004390. It will meet, or exceed, the original TDC filter specification.


Dust Collector Filter Industrial Specifications


In addition to TDC, we make OEM Replacement filters for all the top dust collectors and industrial ventilation in the industry today. We guarantee fit and function at an unbeatable price. If you don't see the industrial filter you need, call us today at (844) 605-3266 . We can cross reference any filter for your specific industiral application.
